Applicable Standard:
Safety Technical Supervision Regulation for Steam Boilers
Type:
Horizontal or Vertical (depending on flue gas flow direction)
Boiler Feed Water:
Softened water or demineralized water
Flue Gas Sources:
Coke oven flue gas, hot gas from annular coolers, hot gas from steel rolling heating furnaces, chemical process gases, etc.
Flue Gas Temperature:
Not limited
Exhaust Gas Temperature:
Approximately 130°C to 200°C (adjustable as needed)
Steam Pressure:
0.6 MPa, 1.6 MPa, 2.5 MPa, 3.82 MPa, etc.
Steam Temperature:
Saturated or Superheated
Key Features:
High Heat Transfer Efficiency
Exceeds conventional waste heat boiler efficiency by over 5%.
Ease of Maintenance
All boiler welds are located externally on the shell, ensuring accessibility for inspection and repairs.
Enhanced Ash Resistance
Far superior ash deposition resistance compared to conventional waste heat boilers.
Stable Performance
Addresses performance degradation and steam output reduction issues common in conventional waste heat boilers.
